304 Stainless Steel Wire

304 stainless steel Wire is the most widely used stainless steel, and like 302, 304 Stainless Steel Wire has good mechanical properties and corrosion resistance. 304 Stainless Steel Wire can withstand attack in a range of corrosive media, and its durability makes 304 Stainless Steel Wire easy to sanitise, meaning 304 Stainless Steel Wire is ideal for kitchen and food applications.

Mechanical Properties Of 304 Stainless At Room Temperature:

Ultimate Tensile Strength – 75 KSI min (517 MPA min)

Yield Strength (0.2% Offset) – 30 KSI min (205 MPA min)

Elongation – 40% min

Hardness – B92 max

Contact Now

Product Details

304 Stainless Steel Wire

304 Stainless Steel Wire is a universal motive stainless alloy usually composed of 18% chromium and 8% nickel. 304 Stainless Steel Wire is the most broadly used stainless spring wire due to the fact of its excessive corrosion resistance residences and correct tensile strength. For spring purposes 304 Stainless Steel Wire is normally furnished in the bloodless drawn condition. 304 Stainless Steel Wire has right power at average temperatures. If proper handled after forming they will set much less than most different spring substances at temperatures up to 500ºF. Type 304 fabric in the spring circumstance is barely magnetic due to the transformation of some martinsite in the drawing operation. The higher the amount of bloodless discount the greater the diploma of magnetism.

Product Parameter

Material	stainless steel wire
Surface	soap coated and bright
Standard	ASTM A580, JIS G4309, EN 10088-3, GB/T4240 and Other Equivalents
Grade	201, 202, 301, 302, 304, 304L, 304H, 304N, 316L, 321, 410, 420, 430
Temper	Annealed and Soft, 1/2 hard, 3/4 hard and full hard conditions
Thickness	0.03-6mm
Type	Stainless steel spring wire/ EPQ wire, Cold heading wire, Stainless Flat steel wire
Packing	Spool or roll
Used	industrial,medical,life field, kitchen usage
