Duplex 2205 Pipe

2205 is a duplex stainless steel. Compared with 316L and 317L austenitic stainless steel, 2205 alloy is superior in resistance to pitting corrosion and crevice corrosion. It has high corrosion resistance. Compared with austenite, It has a lower coefficient of thermal expansion and higher thermal conductivity.

Duplex 2205 Seamless Pipe

Size: 4 - 219mm

Thickness : 0.5 - 20mm

Length: Single, Double Random & Cut Length

Duplex Steel 2205 Welded Pipe

Size: 5.0 - 1219.2 mm

Thickness : 0.5 - 20mm

Length: Single, Double Random & Cut Length

Contact Now

Product Details

Duplex 2205 Pipe

The yield power of 2205 duplex stainless metal is greater than double that of everyday austenitic stainless steel, which approves designers to sketch merchandise with decreased weight and offers this alloy a rate gain over 316,317L. This alloy is in particular appropriate for temperatures in the -50°F/+600°F range. Applications past this temperature vary may also additionally reflect onconsideration on the alloy, however there are some limitations, mainly when utilized to welded structures.

Product Parameter

Size	4 to 219mm W. T.: 0.5 to 20mm
Welded Pipe Size	5.0 - 1219.2 mm
EFW Pipe size	5.0 - 1219.2 mm
Finish	Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF, NO.1, NO.4, 2B, BA, HL, 8K, Mirror finish, etc
Swg & Bwg	10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg.
Schedule	SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Length	Single Random, Double Random, Standard & Cut length Pipe
Form	Duplex 2205 Pipe are available in form of Round, Square, Hollow, Rectangular, Hydraulic, Coiled, Straight Pipes, “U” Shape, Pan Cake Coils etc.
Type	Seamless / ERW/ EFW / Welded / Fabricated / CDW / DOM / CEW Duplex 2205 Pipe
Pipe End	Plain End, Beveled End, Treaded Pipe, Screwed ends
